- 品牌/型號:鵬達塑機/SLBM-RQ700×2
- 制袋規格:300×2/600(mm)
- 生產能力:9000×2/9000(個/h)
- 電動機功率:1。1kw(KW)
- 重量:700(kg)kg
- 外形尺寸:3×1.2×1.7(m)mm
ModelSLBM—RQ700×2/800×2制袋最大寬度Max width of bag-making300/350mm制袋最大長度Max length of bag-making999mm制袋速度Speed of bag-making30—150×2 pc/min總功率Power of total motor≤2.5kw外型尺寸External dimension(L×W×H)3000×1200×1700mm(RQ700×2model)機重Weight≤800kg性能特點:
該機適合加工HDPE、LDPE、LLDPE、PVC、PP、PE等塑料薄膜,生產背心式市場袋、超市袋、印刷袋、食品袋、垃圾袋等民用工業用袋。
1、 主機采用微機電腦控制,步進電機拖料。
2、 任意定長,光電跟蹤,準確平穩,丟標自動停機,送料采用光電控制。
3、 自動計數及可設定報警。
4、 自動恒溫、高溫切斷使袋口封合牢固、平整。
5、 主電機采用變頻電機,高效節能,噪音小,均勻自如
6、 彈簧式出料,自動復位工作。Performance and Characteristics
The machine suits processes HDPE、LLDPE、PVC、PP、PE plastic film and so on.It can produce the market bag,the supermaket bag,prints the bag,food bag,garbage bag,industrial used bag and so on.
1、The whole machine adopts microcomputer co
ntrol and material-pulling by stepping motor.
2、Arbitrary fixed-length, accurate and stable step photoelectric tracking , stopping automatically when the label is lost,
photoelectric co
ntrol feeding.
3、Automatic counting and settable counting alarm.
4、Automatic co
nstant temperature and high-temperature bag-cutting makes the sealing of
bag opening firm and smooth.
5. The host electrical machinery uses the frequency co
nversion electrical machinery,
highly effective energy conservation, noise small and even freely.
6. Spring-loaded leaves the material, reset the work automatically.
